Digital Radiography - easy transitioning and improved efficiency for veterinary practices and animal clinics

Digital radiography is an environmentally friendly and high-quality alternative to analog X-ray imaging in veterinary medicine. Digital and analog imaging systems differ only in terms of image production and image display. Digital X-ray images are subject to the same laws of physics as conventional images. Instead of viewing film in a lightbox, digital images are visualized using a PC and monitor. Thus, the transition to digital radiography requires very few changes in the established workfow for veterinarians.

Digital images can be easily shared via email, for example for expert consultations. Pet owners appreciate being able to take home images on a CD.

If you are not interested in investing in a new X-ray machine at the moment, you can still profit from the excellent quality of digital X-ray images using your old X-ray equipment. Conventional X-ray equipment can be transitioned to digital by the addition of a flat panel detector and a medical display monitor.




nach oben

Is switching to a digital X-ray system a good investment for a veterinarian?

Cost factor digital X-ray

How high are the costs of switching to digital radiology in veterinary medicine? What is the price for new digital X-ray equipment?

In the long run, investments in digital technology pay off in thriving practices. Clients value the improved quality of digital imaging and are willing to pay more. The amortisation rates for digital X-ray systems are shown here.

The ability to order X-rays from within the veterinary management system reduces administrative effort and saves valuable time. With the click of a button, you have instant access to patient records, can order X-rays, and retrieve images from the archive. Sharing X-ray images and documents via electronic storage media is easy and inexpensive.


Currently, two different digital X-ray systems exist: direct radiography (DR) and computed radiography (CR).



nach oben

Digital X-ray Imaging with Direct Radiography (DR) Systems

Digital direct radiography (DR) produces images of outstanding quality. A flat panel detector with of a large number of pixels acts as the image sensor. The detector converts X-ray beams into electrical impulses. The detector is connected to a computer and the image can be viewed immediately after exposure. There are also environmental benefits to using direct radiography. Chemicals are no longer needed to develop the X-ray film. Furthermore, clients appreciate the lower radiation doses for their pets. While the purchase price of direct digital equipment is higher than that of imaging plate (CR) systems, maintenance costs are much reduced.

Digital X ray Direct Radiography for veterinary practices and animal clinics

DR systems can build upon existing conventional X-ray equipment. Digital retrofitting does not involve modification of the X-ray machine or X-ray unit. The system‘s Auto Exposure Detection (AED) works without changes to the running system or cable connections. The new 35 x 43 cm X-ray detectors are designed to fit perfectly into the Bucky tray of existing X-ray units. Direct radiography systems have very high throughput rates for X-ray processing.

nach oben

 Choose the digital X-ray system (DR) that meets your needs:

Amadeo V

Amadeo V mini II for the small animal practice: Digital veterinary X-ray system with flat table top + monitor with X-ray software
The Amadeo V mini II X-ray unit has been specially designed for the requirements in veterinary medicine and is particularly suitable for small veterinary practices. The completely flat 4-way floating table without upstands will convince you. This veterinary X-ray system is a completely in-house creation "Made in Germany" by OR Technology and the result of close cooperation with veterinarians and university institutions.


Röntgensystem für den Standard-Steckdosenbetrieb mit schwimmender Tischplatte

Amadeo V nano II: Space-saving X-ray system for standard wall socket outlet operation with floating table top
The Amadeo V nano II X-ray unit was specially designed for the requirements in veterinary medicine and is particularly suitable for small animal practices. The completely flat 4-way floating table without upstands will inspire you. This veterinary X-ray system is again an in-house development "Made in Germany" by OR Technology and the result of close cooperation with veterinarians and university institutions.


Amadeo V

Amadeo V Systems: A complete DR X-ray system including patient positioning table with floating tabletop
The Amadeo V system is designed for use in veterinary practices and includes all components and functions necessary for digital X-ray imaging without cassettes – including patient positioning table with floating tabletop, three-phase generator, computer and monitor, as well as the dicomPACS®DX-R acquisition and diagnostic software.


Medici vet kabellgebunden

Medici DR Systems: Flat panel (DR) retrofit kit for your existing X-ray system
Is the time ripe for your veterinary practice and animal patients to benefit from the advantages of digital X-ray imaging? Are you looking for a digital detector system that connects to your existing X-ray unit, is easy to install, straightforward to operate, and generates professional and reproducible images? Customise your digital X-ray system with Medici DR and choose from a wide array of flat panel models and sizes.


Digitales Röntgen mit Leonardo mini Koffer für die Tiermedzin

Leonardo DR mini II: Portable digital radiology system in a custom-made suitcase for mobile use in stables and clinics
Compact, lightweight and functional – that’s what the sleek and well-designed Leonardo DR mini is all about. With a weight of only 9.5 kg, the Leonardo DR mini is one of the lightest portable X-ray systems worldwide. The entire system is ideally suited for mobile and stationary radiography in veterinary practices, equine and mixed animal clinics, and research facilities.


Leonardo nano vet

Leonardo DR nano: Amazingly light, portable DR X-ray system in a backpack
The Leonardo DR nano consists of only two components: a wireless X-ray detector and a laptop. Weighing just under 8 kg (including carrying case, laptop, accessories and flat panel detector), the system is one of the lightest portable X-ray solutions worldwide.



nach oben

Digital Radiology using Cassettes with Imaging Plates for Veterinary Practices and Clinics

X-ray inspection using imaging plates functions with cassettes of the same size and shape as conventional film radiography. After the normal X-ray procedure, the cassette is placed into a X-ray scanner and read out.

X raying workflow changes only minimally with a computed radiography CRsystem

Digital images are generated, saved and available for viewing on a computer monitor within seconds (computed radiography; CR). Imaging plate (IP) systems using cassettes are cost-saving X-ray solutions ideal for small animal practices or as a backup in a veterinary clinic. The existing X-ray unit must not be retrofitted. This technology produces high quality digital images.


Choose the perfect Divario product to complete your cost-effective CR system:

Divario T2

Divario CR-T2: Compact, high-speed desktop unit for standard X-ray examinations in veterinary medicine
The Divario CR-T2 is a desktop imaging plate reader for veterinary digital radiography with a maximum throughput of 73 cassettes per hour. In high-speed mode (5 pixel/mm), the processing rate of the new Divario is 70 % higher than that of older CR systems.

Divario Softwarepaket

Divario CR Software Package: Acquisition and diagnostic software for CR systems
dicomPACS®DX-R is a professional acquisition software for X-ray images generated by diverse CR units (computed radiography with imaging plates). The software also controls the operation of X-ray generators and X-ray units from various manufacturers, ensuring an efficient and orderly workflow. The straightforward and user-friendly interface functions via touchscreen and mouse.

Divario CR F Dental Premium

Divario CR-F Dental Premium: Digital radiography system for veterinary medicine
The quick and cost-effective Divario CR-F dental premium system delivers high-quality, digital X-rays. The system is compact and affordable, and enhances overall productivity in veterinary practices and animal hospitals. The dental reader combines an sleek design with a powerful, easy-to-operate technology. The Divario system also includes an automatic imaging plate (IP) input tray and a complete range of reusable bitewing and intraoral plates for efficient positioning.



nach oben

PACS - Picture Archiving and Communication Systems

Picture Archiving and Communication Systems (PACS) are user-friendly software solutions for administering the production and use of X-ray images: from exposure to image analysis, archival storage and file sharing.

The software enables users to quickly and easily view and share images. Depending on the manufacturer,  systems can include numerous advanced features including electronic fax, document management, operative reports and X-ray histories. Software modules for 3D reconstruction, surgical planning, voice recognition, and statistics can also be integrated.


PACS & Digital Image Processing in Veterinary Medicine

Switching to digital brings new possibilities for analysing and viewing X-rays. For example, special filters make soft tissues and bones visible on a single image. An array of special functions, including measurement tools for TPLO, TTA , MMP, distraction index and Buchanan‘s vertebral heart score, make routine diagnoses easier. Editing tools (e.g., arrows, circles, angles) can be used to explain findings to pet owners. As a result, owners can better understand diagnoses and treatment recommendations.

OR Technology‘s dicomPACS®vet can help make your veterinary practice go paperless. Using the dicomPACS®vet software, all images and documents (findings reports, medical history, faxes, etc.) are attached to the digital patient record and are instantly accessible. Ingenious archive and backup solutions guarantee quick access and data security in keeping with relevant international medical products laws. Furthermore, the software can easily be integrated into all common veterinary practice management systems. For more information about PACS for veterinarians, click here.


nach oben

Summary of the benefits of digital radiography:


Immediate access to all digital patient records, including X-ray images, as well as documents from animal practices and clinics


Digital radiography saves time and materials

No chemicals

Some chemicals used in conventional radiography represent an occupational health hazard, are irritating and have an unpleasant odour

No loss of information

Lost hard copies of X-ray images and patient records are a thing of the past

Space saving

Archival storage of analog film material is costly in terms of space, money and time

Efficient communication

Efficient information exchange with experts via internet and DICOM cloud solutions; owner’s can be given X-rays images on a CD

Improved diagnostics

Excellent images and a multitude of image processing options


nach oben

Interface & Integration

Software interface

A PACS can be integrated with the veterinary administration software through special interfaces. All X-ray information is automatically saved in the electronic patient file. Double entries are a thing of the past and no information is lost.


Perfectly integrated

Imaging equipment for X-ray, ultrasound and MRI can be integrated into the existing computer network. Furthermore, faxes and other digital documents can be attached to the patient record. With the appropriate software solution, all information for a given patient is available at the click of a button and can be shared with other caregivers. The digital coordination of all data pertaining to a patient means that the full medical record can be accessed for many years in the future.



Existing hardware can readily be integrated into the new system. Additional components such as printers, X-ray film scanners and other hardware can be purchased and integrated into the network at a time. Please consult your PACS provider concerning the specifications and requirements for servers, work stations and monitors.
