The portable X-ray backpack system for radiographic testing

Just sling the lightweight Leonardo DR nano backpack over your shoulder and head off to your next materials testing or quality inspection appointment. OR Technology‘s portable and digital Leonardo DR nano delivers high-quality X-ray images perfect for detecting even the smallest deviations during daily inspections. The portable and robust complete system weighs only 8 kg and is your best bet for quick and reliable X-ray imaging at even the most remote locations.

The Leonardo DR nano consists of only two components: a wireless X-ray detector and a laptop with the professional acquisition and analysis software, ORinspect. The system is ideal for mobile radiographic testing, any time and any place. Getting tangled up in annoying cables is a thing of the past!  The Leonardo‘s straightforward user interface makes it easy for staff to generate excellent X-ray images.

The Leonardo DR nano system is also well suited for use in confined spaces. The X-ray unit and detector have a wireless connection to the software on the laptop. The X-ray detector and laptop can be stationed up to 10 m apart and still function optimally.







Two versions of the Leonardo DR nano system are available:

1.

Leonardo DRw nano 1210: mobile X-ray system with wireless X-ray detector, format 24x30cm

2.

Leonardo DRw nano 1417: mobile X-ray system with wireless X-ray detector, format 35x43cm

Features & Benefits of the Leonardo DR nano System

Wireless X-ray imaging

Quickly deployable and hassle free

The wireless X-ray detector is available in two sizes (10 x 12 inches and 14 x 17 inches). When used together with a battery-powered HF X-ray generator, X-ray imaging is completely wireless.

The smallest and lightest DR system

Easy to transport, quick to set up

The extremely compact Leonardo DR nano is stowed in a well-designed and sturdy carrying case (also functions as a backpack). Weighing just under 8 kg (including laptop, accessories and detector), the entire unit can easily be carried to remote locations. Portable battery-operated X-ray generators (> 6.8 kg) make the system fully operable in the field. Once on site, the Leonardo DR nano can be assembled quickly and easily.

Perfectly stowed

Well organized and safe for transport

All components are stowed in custom-fitted and sealable compartments in the lightweight backpack. All-round padding offers shock protection to the flat panel detector and laptop.

Excellent image quality

Fantastic images thanks to state-of-the-art technology

The wireless detector boasts outstanding image quality with up to 5 lp/mm resolution.

Quick

Quick patient processing and well-documented workflow

X-ray images are available for viewing and evaluation within 6-8 seconds of triggering.

User-friendly

Straightforward handling even for unspecialised staff

ORinspect, the professional acquisition and control software for radiographic testing, sports an intuitive and modern graphical user interface. All examinations are conducted comfortably at a single monitor.

Always on call

The integrated acquisition and control software provides global, rapid and inexpensive consultations (via e-mail or cloud services) in compliance with safety and privacy regulations. The only requirement is an internet connection.

ORinspect: Professional acquisition and control software for radiographic testing (RT)

PACS Basispaket Materialprfung

The heart of each Leonardo NDT system is the  ORinspect X-ray acquisition and control software developed by OR Technology.

The software controls X-ray generators and X-ray units of various manufacturers, providing a smooth and structured workflow. An intuitive and user friendly GUI (graphical user interface), operated by touchscreen or mouse, completes the system.

The professional image processing can be adapted to individual user needs and offers outstanding image quality. It has been specially developed to enable material-specific optimisation, guaranteeing the highest quality of X-ray images.

[more information...]

  • Brochure Strong Workmate for Non Destructive Testing (RT)
    Our portable digital systems generate images in the highest quality for detecting minimal deviations for your inspection requirements.

  • Product information flat panel PerkinElmer 3543, wireless
    Excellent image quality, pixel resolution of over 100µm, fits into a conventional cassette Bucky tray so that X-ray systems don't have to be modified, active area of 14”x17” (35x43cm)

  • Product information flat panel detector XenOR 35CW, wireless
    Compact flat panel detector in cassette size developed for mobile and stationary radiography, weighing only 3.7kg and offering an active area of 14”x17” (35x43cm) and providing the freedom of wireless operation

  • Product information XenOR 24CW, wireless
    Compact and robust flat panel detector in a splash proof aluminum case and shock absorbing rubber edges, specially for outdoor use, active area of 10”x12” (25x30cm)

Optional add-ons

Amadeo P

Amadeo P  Practical portable and light-weight generators
Due to their low weight, user-friendly operation and integrated interface they can be used in numerous applications in practices, clinics and for out-patient purposes.



PACS MobileView Materialpruefung

dicomPACS®MobileView  the web-based viewer for mobile devices
The web-based viewer contains all the basic functions for viewing images. You can view images virtually with any browser on mobile devices. dicomPACS®MobileView offers a previously unknown degree of mobile freedom, the images are available anywhere.



PACS Vermessung Materialpruefung

dicomPACS®  the sophisticated and high-tech image management solution
The dicomPACS® software acquires, processes, transfers and archives images. Thanks to a diverse array of special functions, the dicomPACS®  can be customised for many applications.



Wandstative Wandhalterungen Materialpruefung


Trolley stands and cassette holder for digital X-ray
A range of trolley stands and cassette holders can be found here.

Technical specifications for Leonardo DR nano

Carrying case (backpack) and accessories bag
  • For 14" x 17" or 10“ x 12“ detectors with and without protection box
  • Outer dimensions: 50 x 49 x 12 cm
  • Well-padded, with a sturdy protective frame and shoulder strap
  • Water-repellent for rain protection
  • All important accessories have their own sealable, custom-fit compartments
Tablet PC or laptop

CPU Intel®, 8 GB RAM, 256 GB hard drive,

1920 x 1080 resolution, 15.6" display, USB 3.0, wireless LAN 802.11 b/g/n

Direct radiography detector 24x30 cm (10“x12“) wireless (Leonardo DRw nano 1210)

Wireless X-ray imaging!

  • Fits into existing Bucky tray without modifications (in place of  X-ray film cassettes)
Direct radiography detector 35 x 43 cm (14" x 17") wireless (Leonardo DRw nano 1417)

Wireless X-ray imaging!

  • Fits into existing Bucky tray without modifications (in place of  X-ray film cassettes)
Battery charger and rechargeable batteries
  • Fast-charging, long-lasting batteries plus battery charger
  • Battery charge time: 3 hours
ORinspect software package

Professional console software with modern graphical user interface integrated:

  • ORinspect  DICOM Send SCU
  • ORinspect DICOM image CD
  • ORinspect  Cognition Optimised Processing

Optional components for the Leonardo DR-nano system

X-ray detector mounting system VersariX
  • Height-adjustable, suited for objects in standing position
  • X-ray detector can be attached with or without protective casing
  • Detector holder (400g) fits in Leonardo carrying case
Detector casing
  • Protective casing for 14" x 17" detector
  • Max. load for entire surface: 1040 kg
  • Max. point load: 146 kg/mm
Protective case for detector

Available in various sizes:

  • For 35 x 43 cm (14“ x 17“) detectors
  • For 24 x 30 cm (10“ x 12“) detectors

Available with and without grid

Golden Engineering XR200 battery-operated with pulse technology

150 kV pulse X-ray device ideal for radiological testing, unit‘s high powered battery and low overall weight guarantee easy handling

  • includes hard shell carrying case and remote cable
  • peak output 150 kV, 2.6 mR – 4.0 mR per pulse, focal spot 3.0 x 3.0 mm
  • dimensions 318 x 115 x 190 mm, weight 5.5 kg
  • Golden Engineering XR150 battery-operated Portable battery-operated X-ray unit with pulse technology ideal for NDT and the security sector
  • includes hard shell carrying case and remote cable
  • peak output 150 kV, 1.0 mR per pulse, focal spot 3.0 x 3.0 mm
  • dimensions 273 x 104 x 80 mm, weight 2.1 kg
  • Golden Engineering XRS-3 battery-operated Portable battery-operated X-ray unit with pulse technology ideal for NDT and the security sector
  • includes hard shell carrying case and remote cable
  • peak output 270 kV, 2.6 mR – 4.0 mR per pulse, focal spot 3.0 x 3.0 mm
  • dimensions 356 x 115 x 190 mm, weight 5.4 kg
  • Mobile X-ray tables and stands

    A wide range of modern X-ray tables and carrying systems is available. Feel free to contact us for more information!
