Amadeo PTM Series
Portable X-ray machines for emergency medicine – battery-powered for rapid mobile diagnostics
Advice wanted
Our Amadeo P models at a glance
The most powerful – ideal for demanding imaging in mobile and portable applications by NGOs, medical services and hospitals
Amadeo P-125/8230STM
- Compact, portable 5 kW X-ray generator with integrated battery; up to 125 kV
- For precise and detailed imaging
- Battery and mains operation
- Double focus 0.6 mm / 1.8 mm
- Weight: 13 kg (use with tripod recommended)
- Wireless battery operation with up to 200 images or > 8 hours standby time
- User-friendly touchscreen
- Robust, compact, splash-proof housing with rotating collimator
For demanding mobile applications for NGOs, medical services and hospitals
Amadeo P-100/35HBTM
- Compact 2.4 kW high-frequency X-ray generator, 2.4 kW to 80 kV
- Reliable and powerful
- Battery and mains operation (automatic mains adaptation)
- Focus 1.2 mm × 1.2 mm
- Robust and mobile: only 14.2 kg
- Powerful lithium polymer battery, charging time approx. 180 minutes
- With integrated dual laser
- High-brightness collimator with integrated timer
For standard imaging in mobile and portable applications by NGOs, medical services and hospitals
Amadeo P-100/20HBTM
- Robust, portable 1.6 kW high-frequency X-ray generator, 40 to 100 kV
- Battery and mains operation (automatic mains adaptation)
- Focus 1.2 mm × 1.2 mm
- Only 11.2 kg including battery
- Up to 300 images with one battery charge (lithium polymer, charging time approx. 180 minutes)
- Precise dual laser
Comprehensive and regional service
for your digital X-ray system
Our regional service team provides rapid support, maintenance and customised solutions – on site or via remote maintenance. This ensures that your X-ray system remains reliably operational.
Overview of services
That’s why buying from OR Technology is
the best decision for you.
You can rely on the high quality of our products.
Thanks to international quality standards, you can rely on a secure and powerful solution.
We offer you a customised software solution “Made in Germany.”
Rapid on-site assistance and comprehensive support by telephone or remote maintenance are available to you at any time.
With thousands of systems installed worldwide, you can rely on proven products that many trust.
You can trust us based on our decades of experience.
The complete picture – in our catalogues
Product information
Amadeo P-100/35HB
Battery-powered portable monoblock X-ray machine with high-frequency technology
Product information
Amadeo P-100/20HB
Portable, battery-powered monoblock X-ray unit with high-frequency technology
Product catalogue
Digital X-ray and image management
The guide for clinics and medical practices
Extensions to the complete digital X-ray system
Leonardo DR mini III
Portable X-ray system in a handy case
An Amadeo P X-ray machine combined with the Leonardo case solution offers a mobile X-ray solution that is particularly suitable for outdoor use. The Leonardo DR mini III combines X-ray detector technology with powerful software for diagnosis and acquisition. It is suitable for both stationary use and outpatient care in the home care sector and in aid missions by NGOs.
Leonardo DR nano
Very lightweight, portable X-ray system in a rucksack
An Amadeo P X-ray machine in combination with the Leonardo DR nano is the ideal solution for mobile X-ray imaging. The Leonardo DR nano consists solely of a wireless X-ray detector and a tablet PC/notebook. Weighing only approx. 8 kg (including bag, notebook, accessories and detector), it is one of the lightest portable X-ray solutions in the world.
- Leonardo DR mini III
Leonardo DR mini III
Portable X-ray system in a handy case
Learn more
An Amadeo P X-ray machine combined with the Leonardo case solution offers a mobile X-ray solution that is particularly suitable for outdoor use. The Leonardo DR mini III combines X-ray detector technology with powerful software for diagnosis and acquisition. It is suitable for both stationary use and outpatient care in the home care sector and in aid missions by NGOs. - Leonardo DR nano
Leonardo DR nano
Very lightweight, portable X-ray system in a rucksack
Learn more
An Amadeo P X-ray machine in combination with the Leonardo DR nano is the ideal solution for mobile X-ray imaging. The Leonardo DR nano consists solely of a wireless X-ray detector and a tablet PC/notebook. Weighing only approx. 8 kg (including bag, notebook, accessories and detector), it is one of the lightest portable X-ray solutions in the world.
